Huixin H18N20D
Manufacturer:
Huixin
Asian Brands
Mfr. Part #:
H18N20D
Package:
TO-252
Customer #:
Key Attributes:
MOSFET N-CH 200V 18A TO-252
Description:
200V 18A 95mΩ@10V 2.1V 1 N-channel 83W TO-252 Single FETs, MOSFETs RoHS
Datasheet:
Huixin H18N20D
Products Specifications
Manufacturer:
Package:
TO-252
Drain to Source Voltage:
200V
Current - Continuous Drain(Id):
18A
RDS(on):
95mΩ@10V
Operating Temperature -:
-55℃~+175℃
Gate Threshold Voltage (Vgs(th)):
2.1V
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
5.5pF
Number:
1 N-channel
Input Capacitance(Ciss):
491pF
Pd - Power Dissipation:
83W
Output Capacitance(Coss):
22pF
Gate Charge(Qg):
9.8nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 2500 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
