HUAYI HYG013N04NA1P

HUAYI HYG013N04NA1P

Name: HUAYI HYG013N04NA1P
Brand: HUAYI

Manufacturer: HUAYI Asian Brands

Mfr. Part #: HYG013N04NA1P

Package: TO-220FB

Customer #:

Key Attributes: N-Channel, Current: 260A, Voltage: 40V

Description: 40V 260A 1.6mΩ@10V 4V@250uA 1 N-channel 230W TO-220FB Single FETs, MOSFETs RoHS

Datasheet: HUAYI HYG013N04NA1P

Products Specifications

Category:

Discrete Semiconductors/FETs, MOSFETs/Single FETs, MOSFETs

Manufacturer:

HUAYI

Package:

TO-220FB

Drain to Source Voltage:

40V

Current - Continuous Drain(Id):

260A

Operating Temperature -:

-55℃~+175℃

RDS(on):

1.6mΩ@10V

Gate Threshold Voltage (Vgs(th)):

4V@250uA

Type:

N-Channel

Reverse Transfer Capacitance (Crss@Vds):

1.05nF

Number:

1 N-channel

Output Capacitance(Coss):

1.502nF

Input Capacitance(Ciss):

11.62nF

Pd - Power Dissipation:

230W

Gate Charge(Qg):

265nC@10V

Additional Information

Type	Details
Minimum	1
Multiple	1
Standard Packaging	1000
Sales Unit	Piece

Compliance & Export Codes

Type	Details
RoHS
ECCN	EAR99
CNHTS	8541290000
USHTS	8541290095
TARIC	8541290000
CAHTS	8541290000
BRHTS	85412910
INHTS	85412900
MXHTS	8541.29.99

About Product

Get Best Price

Inquiry

Negotiate

Payment

Shipping

HUAYI

323 Products

Asian Brand

HUAYI, also known as Hymexa, was established in 2017 and is a high-tech enterprise under the Huatian Electronics Group, focusing on the research, design, packaging, testing, and sales of semiconductor power devices. Its main product lines include MOSFET, Trench MOSFET, and SGT MOSFET.
