Products Specifications
Manufacturer:
Package:
SOP-8
Pd - Power Dissipation:
2.5W
Configuration:
Half-Bridge
Drain to Source Voltage:
30V
Current - Continuous Drain(Id):
7A;6A
Operating Temperature -:
-55℃~+150℃
RDS(on):
18mΩ;35mΩ
Gate Threshold Voltage (Vgs(th)):
2.5V
Type:
N-Channel + P-Channel
Reverse Transfer Capacitance (Crss@Vds):
40pF;56pF
Number:
1 N-Channel + 1 P-Channel
Input Capacitance(Ciss):
370pF;530pF
Output Capacitance(Coss):
54pF;70pF
Gate Charge(Qg):
7.2nC@4.5V;1nC@15V
Additional Information
| Type | Details |
|---|---|
| Minimum | 10 |
| Multiple | 10 |
| Standard Packaging | 3000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
