Products Specifications
Manufacturer:
Package:
SOT-23-6L
Configuration:
Half-Bridge
Drain to Source Voltage:
20V
Current - Continuous Drain(Id):
6.3A
RDS(on):
17mΩ@4.5V;30mΩ@4.5V
Operating Temperature -:
-55℃~+150℃
Gate Threshold Voltage (Vgs(th)):
1.2V;700mV
Type:
N-Channel + P-Channel
Reverse Transfer Capacitance (Crss@Vds):
35pF;85pF
Number:
1 N-Channel + 1 P-Channel
Output Capacitance(Coss):
49pF;132pF
Input Capacitance(Ciss):
310pF;830pF
Pd - Power Dissipation:
1W
Gate Charge(Qg):
4.6nC@4.5V;8.8nC@4.5V
Additional Information
| Type | Details |
|---|---|
| Minimum | 20 |
| Multiple | 20 |
| Standard Packaging | 3000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
HL
282 Products
HL is located in Shenzhen, China, and is a national high-tech enterprise focusing on MCUs, motor drivers, and system control. The company primarily produces microcontroller units (MCUs), motor driver chips, and related products for system control.
