Products Specifications
Manufacturer:
Package:
TO-252
Drain to Source Voltage:
40V
Current - Continuous Drain(Id):
52A
Operating Temperature -:
-55℃~+150℃
RDS(on):
13mΩ@10V,20A
Gate Threshold Voltage (Vgs(th)):
2.5V@250uA
Type:
P-Channel
Reverse Transfer Capacitance (Crss@Vds):
289pF
Number:
1 P-Channel
Input Capacitance(Ciss):
3.8nF
Output Capacitance(Coss):
329pF
Pd - Power Dissipation:
45W
Gate Charge(Qg):
68nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 2500 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
HL
282 Products
HL is located in Shenzhen, China, and is a national high-tech enterprise focusing on MCUs, motor drivers, and system control. The company primarily produces microcontroller units (MCUs), motor driver chips, and related products for system control.
