hanxia HX TS152605A 160gf
Manufacturer:
hanxia
Asian Brands
Mfr. Part #:
HX TS152605A 160gf
Package:
SMD-4P,2.5x1.6mm
Customer #:
Key Attributes:
SWITCH TACTILE SPST 160gf SMD
Description:
Tactile Switch SPST 160gf 0.55mm SMD (SMT) Tab 2.5mm x 1.6mm Surface Mount
Datasheet:
hanxia HX TS152605A 160gf
Products Specifications
Category:
Manufacturer:
Package:
SMD-4P,2.5x1.6mm
with Bracket:
Without Bracket
PressForce:
1.6N
Length:
2.5mm
Height:
0.55mm
Voltage Rating:
12V
Switching Life:
200,000 Cycles
Operating Temperature:
-40℃~+85℃
Width:
1.6mm
Installation Method:
Surface Mount,Vertical
Termination Style:
SMD(SMT) Tab
Actuator Style:
-
With Lamp:
No
Circuit:
SPST
Actuator/Cap Color:
Silver
IP Rating:
IP67
Contact Current:
50mA
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 10000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8536500090 |
| USHTS | 8536507000 |
| TARIC | 8536500300 |
| CAHTS | 8536501000 |
| BRHTS | 85365090 |
| INHTS | 85365090 |
| MXHTS | 8536.50.09 |
