GL GL50N03A4
Manufacturer:
GL
Asian Brands
Mfr. Part #:
GL50N03A4
Package:
TO-252-2
Customer #:
Key Attributes:
N-Channel, Current:50A, Voltage:30V
Description:
30V 50A 11mΩ@10V 3V@250uA 1 N-channel 60W TO-252-2 Single FETs, MOSFETs RoHS
Datasheet:
GL GL50N03A4
Products Specifications
Manufacturer:
Package:
TO-252-2
Drain to Source Voltage:
30V
Current - Continuous Drain(Id):
50A
Operating Temperature -:
-55℃~+175℃
RDS(on):
11mΩ@10V
Gate Threshold Voltage (Vgs(th)):
3V@250uA
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
180pF
Number:
1 N-channel
Output Capacitance(Coss):
240pF
Pd - Power Dissipation:
60W
Input Capacitance(Ciss):
1.8nF
Gate Charge(Qg):
23nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 2500 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
