Fuji Electric FGW50N60HD
Manufacturer:
Fuji Electric
Mfr. Part #:
FGW50N60HD
Package:
TO-247
Customer #:
Key Attributes:
FGW50N60HD Discrete IGBT (High-Speed V Series) 600V / 50A
Description:
360W 600V TO-247 Single IGBTs RoHS
Datasheet:
Fuji Electric FGW50N60HD
Products Specifications
Manufacturer:
Package:
TO-247
Td(off):
310ns
Pd - Power Dissipation:
360W
Td(on):
35ns
Collector-Emitter Breakdown Voltage (Vces):
600V
Reverse Transfer Capacitance (Cres):
160pF
Gate-Emitter Threshold Voltage (Vge(th)@Ic):
4V@50mA
Operating Temperature:
-40℃~+175℃
Pulsed Current- Forward(Ifm):
150A
Output Capacitance(Coes):
210pF
Reverse Recovery Time(trr):
25ns
Switching Energy(Eoff):
1.7mJ
Turn-On Energy (Eon):
1.4mJ
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 30 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541600000 |
| USHTS | 8541600080 |
| TARIC | 8541600000 |
| CAHTS | 8541600010 |
| BRHTS | 85416010 |
| INHTS | 85416000 |
| MXHTS | 8541.60.01 |
