Products Specifications
Manufacturer:
Package:
TO-263
Drain to Source Voltage:
85V
Current - Continuous Drain(Id):
110A
Operating Temperature -:
-55℃~+175℃
RDS(on):
6.8mΩ@10V
Gate Threshold Voltage (Vgs(th)):
4V@250uA
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
256pF
Number:
1 N-channel
Output Capacitance(Coss):
482pF
Pd - Power Dissipation:
202W
Input Capacitance(Ciss):
5.56nF
Gate Charge(Qg):
152nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 800 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
