Products Specifications
Manufacturer:
Package:
TO-252
Drain to Source Voltage:
40V
Current - Continuous Drain(Id):
80A
Operating Temperature -:
-55℃~+175℃
RDS(on):
6.8mΩ@10V;9.5mΩ@4.5V
Gate Threshold Voltage (Vgs(th)):
1.65V@250uA
Reverse Transfer Capacitance (Crss@Vds):
176pF
Number:
-
Output Capacitance(Coss):
195pF
Input Capacitance(Ciss):
2.246nF
Pd - Power Dissipation:
42W
Gate Charge(Qg):
52nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 2500 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
FM
271 Products
Founded in 2001, Shenzhen Fuman Electronics Group Co., Ltd. is a state-level high-tech enterprise engaged in the research and development, packaging, testing and sales of high-performance analog and digital-analog integrated circuits. Currently has more than 400 kinds of IC products in the field of consumption including power management, LED driver, MOSFET and so on.
