DOINGTER DOS27517
Manufacturer:
DOINGTER
Asian Brands
Mfr. Part #:
DOS27517
Package:
SOT-23-5
Customer #:
Description:
SOT-23-5 Gate Drivers RoHS
Datasheet:
DOINGTER DOS27517
Products Specifications
Manufacturer:
Package:
SOT-23-5
Operating Temperature:
-40℃~+125℃@(Tj)
Input Logic Level - Low:
800mV
Propagation Delay tpLH:
30ns
Peak Output Current(Source):
4A
Propagation Delay tpHL:
60ns
Peak Output Current(Sink):
4A
Rise Time:
10ns
Fall Time:
10ns
Quiescent Current(Iq):
180uA
Load Type:
MOSFET;IGBT
Input Voltage (Vin):
5V~25V
Input Logic Level - High:
1V~2.5V
Driven Configuration:
Low Side
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 3000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8542399000 |
| USHTS | 8542390001 |
| TARIC | 8542399000 |
| CAHTS | 8542390000 |
| BRHTS | 85423999 |
| INHTS | 85423900 |
| MXHTS | 8542.39.99 |
