Doeshare DP3415
Manufacturer:
Doeshare
Asian Brands
Mfr. Part #:
DP3415
Package:
SOT-23
Customer #:
Key Attributes:
MOSFET P-CH 20V 5A SOT-23
Description:
P-Channel 20V 5A 1.3W Surface Mount SOT-23
Datasheet:
Doeshare DP3415
Products Specifications
Manufacturer:
Package:
SOT-23
Drain to Source Voltage:
20V
Current - Continuous Drain(Id):
5A
RDS(on):
120mΩ@1.8V
Operating Temperature -:
-55℃~+150℃
Gate Threshold Voltage (Vgs(th)):
950mV@250uA
Type:
P-Channel
Reverse Transfer Capacitance (Crss@Vds):
116pF@10V
Number:
1 P-Channel
Input Capacitance(Ciss):
940pF@10V
Pd - Power Dissipation:
1.3W
Gate Charge(Qg):
60nC@4.5V
Additional Information
| Type | Details |
|---|---|
| Minimum | 10 |
| Multiple | 10 |
| Standard Packaging | 3000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
