DIODES DMNH6022SSD-13
Manufacturer:
DIODES
Mfr. Part #:
DMNH6022SSD-13
Package:
SO-8
Customer #:
Description:
60V 22.6A 2.1W Surface Mount SO-8
Datasheet:
DIODES DMNH6022SSD-13
Products Specifications
Manufacturer:
Package:
SO-8
Drain to Source Voltage:
60V
Current - Continuous Drain(Id):
22.6A
Operating Temperature -:
-55℃~+175℃
RDS(on):
27mΩ@10V
Gate Threshold Voltage (Vgs(th)):
3V@250uA
Reverse Transfer Capacitance (Crss@Vds):
54pF@25V
Number:
-
Pd - Power Dissipation:
2.1W
Input Capacitance(Ciss):
2.127nF@25V
Gate Charge(Qg):
32nC@10V
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
DIODES
6026 Products
Diodes Incorporated is a leading global manufacturer and supplier of high-quality application specific standard products within the broad discrete, logic, analog and mixed-signal semiconductor markets.
