Broadcom ACPL-355JC-500E
Manufacturer:
Broadcom
Mfr. Part #:
ACPL-355JC-500E
Package:
SO-16
Customer #:
Description:
10A 5V 35ns 33ns 1.4V SO-16 Isolators - Gate Drivers RoHS
Datasheet:
Broadcom ACPL-355JC-500E
Products Specifications
Manufacturer:
Package:
SO-16
Output Current:
10A
Operating Temperature:
-40℃~+110℃
Isolation voltage(Vrms):
5kV
Propagation Delay(tpd):
140ns;140ns
Reverse Voltage:
5V
Load Type:
MOSFET;IGBT
Voltage - Supply:
4.5V~5.5V;15V~30V
Rise Time:
35ns
Fall Time:
33ns
Voltage - Forward(Vf):
1.4V
CMTI(kV/us):
100kV/us
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | - |
| USHTS | - |
| TARIC | - |
| CAHTS | - |
| BRHTS | - |
| INHTS | - |
| MXHTS | - |
