Broadcom ACPL-W340-000E
Manufacturer:
Broadcom
Mfr. Part #:
ACPL-W340-000E
Package:
SOIC-6-6.8mm
Customer #:
Description:
800mA 5V 16mA 1.55V 1.55V DC SOIC-6-6.8mm Isolators - Gate Drivers RoHS
Datasheet:
Broadcom ACPL-W340-000E
Products Specifications
Category:
Manufacturer:
Package:
SOIC-6-6.8mm
Output Current:
800mA
Operating Temperature:
-40℃~+105℃
Propagation Delay(tpd):
200ns;200ns
Input threshold current:
4mA
Isolation voltage(Vrms):
5kV
Reverse Voltage:
5V
Forward Current:
16mA
Voltage - Supply:
1.55V
Voltage - Forward(Vf):
1.55V
CMTI(kV/us):
50kV/us
Number of Channels:
1
Input Type:
DC
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 100 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541490000 |
| USHTS | 8541491010 |
| TARIC | 8541490000 |
| CAHTS | 8541490090 |
| BRHTS | 85414900 |
| INHTS | 85414900 |
| MXHTS | 8541.40.02 |
