Broadcom ACPL-K33T-560E
Manufacturer:
Broadcom
Mfr. Part #:
ACPL-K33T-560E
Package:
SOP-8-6.8mm
Customer #:
Key Attributes:
Automotive 2.5 A Peak High Output Current SiC MOSFET and IGBT Gate Drive Optocoupler with Rail-to-Rail Output Voltage in Stretched S0-8
Description:
2.5A 6V 15ns 15V~30V 15ns 1.5V SOP-8-6.8mm Isolators - Gate Drivers RoHS
Datasheet:
Broadcom ACPL-K33T-560E
Products Specifications
Category:
Manufacturer:
Package:
SOP-8-6.8mm
Power Dissipation:
550mW
Output Current:
2.5A
Operating Temperature:
-40℃~+125℃
Isolation voltage(Vrms):
5kV
Propagation Delay(tpd):
120ns;120ns
Reverse Voltage:
6V
Load Type:
MOSFET;IGBT
Rise Time:
15ns
Voltage - Supply:
15V~30V
Fall Time:
15ns
Voltage - Forward(Vf):
1.5V
CMTI(kV/us):
50kV/us
Number of Channels:
1
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 1000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | - |
| USHTS | - |
| TARIC | - |
| CAHTS | - |
| BRHTS | - |
| INHTS | - |
| MXHTS | - |
