ARK micro FTP0P1N15G
Manufacturer:
ARK micro
Asian Brands
Mfr. Part #:
FTP0P1N15G
Package:
TO-220AB
Customer #:
Key Attributes:
MOSFET N-CH 150V 17A TO-220AB
Description:
N-Channel 150V 17A 80W Through Hole TO-220AB
Datasheet:
ARK micro FTP0P1N15G
Products Specifications
Manufacturer:
Package:
TO-220AB
Drain to Source Voltage:
150V
Current - Continuous Drain(Id):
17A
RDS(on):
80mΩ@10V
Operating Temperature -:
-55℃~+150℃
Gate Threshold Voltage (Vgs(th)):
4.8V@50uA
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
36pF
Number:
1 N-channel
Output Capacitance(Coss):
138pF
Pd - Power Dissipation:
80W
Input Capacitance(Ciss):
1.169nF
Gate Charge(Qg):
36.5nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 50 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
ARK micro
81 Products
ARK Microelectronics Co., Ltd.
(hereinafter referred to as "ARK micro") was founded in 2008 and is the only company in China that focuses on depletion-type MOSFET design. The products provide outstanding power handling and power management capabilities in an integrated control manner. All of the company's products are independently developed, and its related technologies have obtained invention patents. ARK micro's products include two product lines: industrial and consumer. The independently developed DMMOS® series products cover the full range of depletion-type MOSFETs. Products are widely used in fast charging, LED, industrial control, electric vehicles, communication circuits, Internet of Things, photovoltaics, server power supplies, and charging piles. ARK micro's products are high-quality, high-performance, and low-cost, recognized and widely used by both domestic and international customers.
