AIPULNION NN2-12S05A3NT
Manufacturer:
AIPULNION
Asian Brands
Mfr. Part #:
NN2-12S05A3NT
Package:
SMD,12.7x8.3mm
Customer #:
Key Attributes:
DC/DC modular power supply, fixed voltage input, isolated unregulated output, output power 2W
Description:
Isolated Module DC DC Converter 5V 400mA 10.8V~13.2V Input
Datasheet:
AIPULNION NN2-12S05A3NT
Products Specifications
Manufacturer:
Package:
SMD,12.7x8.3mm
Height:
7.13mm
Vin:
10.8V~13.2V
Vout:
5V
Operating Temperature:
-40℃~+105℃
Capacitive Load(Max):
2400uF
Ripple:
100mVp-p
Iout:
400mA
Length:
12.7mm
Width:
11mm
Frequency - Switching:
260kHz
Isolation Voltage(Vrms):
3kV
Quiescent Supply Current:
5mA
Conversion Efficiency:
84%
Output Power:
2W
Features:
Short Circuit Protection
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 500 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| ECCN | - |
| CNHTS | - |
| USHTS | - |
| TARIC | - |
| CAHTS | - |
| BRHTS | - |
| INHTS | - |
| MXHTS | - |
