MAXIM MAX4194ESA+T
Manufacturer:
MAXIM
Mfr. Part #:
MAX4194ESA+T
Package:
SO-8
Customer #:
Key Attributes:
Micropower, Single-Supply, Rail-to-Rail, Precision Instrumentation Amplifiers
Description:
100uV Rail-to-Rail Output 6nA 0.06V/us 95dB 93uA 250kHz 1 SO-8 Amplifiers RoHS
Products Specifications
Manufacturer:
Package:
SO-8
Settling time:
60us
Vos - Input Offset Voltage:
100uV
Output Type:
-
Rail to Rail:
Rail-to-Rail Output
Input offset current drift(Ios TC):
15pA/℃
Ib - Input Bias Current:
6nA
Slew Rate:
0.06V/us
Operating Temperature:
-40℃~+85℃
Common Mode Rejection Ratio(CMRR):
95dB
Output Current:
4.5mA
Power Supply Rejection Ratio (PSRR):
120dB
Quiescent Current:
93uA
Gain Bandwidth Product:
250kHz
Input Offset Voltage Drift(Vos TC):
1uV/℃
Single Supply:
2.7V~7.5V
Maximum Power Supply Range (Vdd-Vss):
7.5V
Number of Channels:
1
Input Offset Current(Ios):
1nA
Dual Supply:
-3.75V~-1.35V;1.35V~3.75V
Noise density(eN):
85nV/√Hz@10Hz
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 2500 |
| Sales Unit | Piece |
