ADI AD8222ACPZ-R7
Manufacturer:
ADI
Mfr. Part #:
AD8222ACPZ-R7
Package:
LFCSP-16(4x4)
Customer #:
Key Attributes:
Precision, Dual-Channel Instrumentation Amplifier
Description:
120uV 1nA 2V/us 80dB 1.1mA 7MHz 2 LFCSP-16(4x4) Amplifiers RoHS
Products Specifications
Manufacturer:
Package:
LFCSP-16(4x4)
Settling time:
13us
Vos - Input Offset Voltage:
120uV
Output Type:
Single-Ended
Rail to Rail:
-
Input offset current drift(Ios TC):
0.5pA/℃
Ib - Input Bias Current:
1nA
Operating Temperature:
-40℃~+85℃
Slew Rate:
2V/us
Common Mode Rejection Ratio(CMRR):
80dB
Output Current:
18mA
Power Supply Rejection Ratio (PSRR):
94dB
Quiescent Current:
1.1mA
Gain Bandwidth Product:
7MHz
Input Offset Voltage Drift(Vos TC):
400nV/℃
Single Supply:
-
Maximum Power Supply Range (Vdd-Vss):
36V
Number of Channels:
2
Input Offset Current(Ios):
500pA
Noise density(eN):
8nV/√Hz@1kHz
Dual Supply:
-18V~-2.3V;2.3V~18V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 1500 |
| Sales Unit | Piece |
