Infineon IKP15N65F5
Manufacturer:
Infineon
Mfr. Part #:
IKP15N65F5
Package:
TO-220-3
Customer #:
Key Attributes:
High speed 5 FAST IGBT in TRENCHSTOP 5 technology copacked with RAPID 1 fast and soft antiparallel diode
Description:
105W 650V TO-220-3 Single IGBTs RoHS
Products Specifications
Manufacturer:
Package:
TO-220-3
Td(off):
150ns
Pd - Power Dissipation:
105W
Td(on):
17ns
Operating Temperature:
-40℃~+175℃
Collector-Emitter Breakdown Voltage (Vces):
650V
Reverse Transfer Capacitance (Cres):
4pF
Gate-Emitter Threshold Voltage (Vge(th)@Ic):
3.2V@0.15mA
Gate Charge(Qg):
38nC@15V
Reverse Recovery Time(trr):
50ns
Switching Energy(Eoff):
40uJ
Turn-On Energy (Eon):
130uJ
Input Capacitance(Cies):
930pF
Pulsed Current- Forward(Ifm):
45A
Output Capacitance(Coes):
24pF
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 50 |
| Sales Unit | Piece |
