TI TPIC5223LD
Manufacturer:
TI
Mfr. Part #:
TPIC5223LD
Package:
-
Customer #:
Key Attributes:
2-Channel Independent Gate-Protected Logic-Level Power DMOS Array, Current:1A, Voltage:60V
Description:
60V 1A 430mΩ@5V 2.2V@1mA 950mW Single FETs, MOSFETs
Products Specifications
Manufacturer:
Package:
-
Drain to Source Voltage:
60V
Current - Continuous Drain(Id):
1A
Operating Temperature -:
-40℃~+125℃
RDS(on):
430mΩ@5V
Gate Threshold Voltage (Vgs(th)):
2.2V@1mA
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
50pF@25V
Input Capacitance(Ciss):
190pF@25V
Pd - Power Dissipation:
950mW
Gate Charge(Qg):
3.8nC@5V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 1 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
Get Best Price
Inquiry
Negotiate
Payment
Shipping
TI
26911 Products
Texas Instruments Incorporated designs and manufactures analog technologies, digital signal processing (DSP) and microcontroller (MCU) semiconductors. TI is a leader in semiconductor solutions for analog and digital embedded and applications processing. A global semiconductor company, TI innovates through design, sales and manufacturing operations in more than 30 countries.
