Wolfspeed CAB011M12FM3T

Wolfspeed CAB011M12FM3T

Name: Wolfspeed CAB011M12FM3T
Brand: Wolfspeed

Manufacturer: Wolfspeed

Mfr. Part #: CAB011M12FM3T

Package: Module

Customer #:

Description: 1.2kV 120A 14mΩ@15V 3.6V@35mA Module Single FETs, MOSFETs RoHS

Datasheet: Wolfspeed CAB011M12FM3T

Products Specifications

Manufacturer:

Wolfspeed

Package:

Module

Drain to Source Voltage:

1.2kV

Current - Continuous Drain(Id):

120A

RDS(on):

14mΩ@15V

Operating Temperature -:

-40℃~+175℃

Gate Threshold Voltage (Vgs(th)):

3.6V@35mA

Type:

N-Channel

Reverse Transfer Capacitance (Crss@Vds):

30pF

Input Capacitance(Ciss):

10.3nF

Gate Charge(Qg):

324nC@15V

About Product

Get Best Price

Inquiry

Negotiate

Payment

Shipping

Wolfspeed

738 Products

International Brand

Wolfspeed was founded in 1987 as the power and RF division of Cree and officially rebranded to Wolfspeed in 2021. The company focuses on silicon carbide (SiC) and gallium nitride (GaN) technologies, primarily producing wide bandgap semiconductor materials, power devices, and RF devices.
