UMW IRS2304STR(UMW)
Manufacturer:
UMW
Asian Brands
Mfr. Part #:
IRS2304STR(UMW)
Package:
SOP-8
Customer #:
Key Attributes:
700V Half Bridge MOSFET/IGBT Gate Driver With BSD
Description:
10V~20V 300mA SOP-8 Gate Drivers RoHS
Datasheet:
UMW IRS2304STR(UMW)
Products Specifications
Manufacturer:
Package:
SOP-8
Input Logic Level - Low:
800mV
Peak Output Current(Sink):
600mA
Quiescent Current(Iq):
120uA
Voltage - Supply:
10V~20V
Operating Temperature:
-40℃~+125℃
Driven Configuration:
Half-Bridge
Propagation Delay tpLH:
130ns
Propagation Delay tpHL:
130ns
Rise Time:
75ns
Current - Output High(IOH):
300mA
Features:
Under Voltage Protection
Fall Time:
35ns
Load Type:
MOSFET;IGBT
Input Logic Level - High:
2.5V
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 2500 |
| Sales Unit | Piece |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
UMW
1816 Products
Guangdong Youtai Semiconductor Co., Ltd.
(hereafter referred to as "UMW") was established in 2013. It is a high-tech enterprise that integrates R&D, design, packaging, and manufacturing of integrated circuits and discrete devices. UMW has passed the ISO9001:2015 quality management system certification, and its products have received UL, CQC, and SGS certifications. UMW is known for its commitment to high-end quality and has earned a strong reputation in markets. Its product lines include power management ICs, low-power LDOs, three-terminal voltage regulators, MOSFETs, optocouplers, rectifier bridges, and logic circuits. These products are widely used in power supplies, instruments, home appliances, communication equipment, automotive electronics, and industrial automation. The company is dedicated to the sustainable development of the semiconductor industry, leveraging its expertise in high technology to provide top-quality products and system solutions. UMW aims to contribute to a har
