THD THD0559-9WV-GF
Manufacturer:
THD
Asian Brands
Mfr. Part #:
THD0559-9WV-GF
Package:
SMD,P=0.5mm(Staggered Pins)
Customer #:
Key Attributes:
CONN FFC FPC 9POS 0.5mm VERTICAL - 1 SIDED CNT SMD
Description:
FFC/FPC Connector 9 Position 0.5mm Pitch Single-side Contact/Vertical Surface Mount -25℃~+85℃
Datasheet:
THD THD0559-9WV-GF
Products Specifications
Manufacturer:
Package:
SMD,P=0.5mm(Staggered Pins)
Locking Feature:
Hinged Lid
Operating Temperature:
-25℃~+85℃
Number of Contacts:
9P
Pitch:
0.5mm
Current Rating:
500mA
Voltage Rating (Max):
50V
Contact Type:
Single-side Contact/Vertical
Mounting Type:
Surface Mount,Vertical
FFC, FCB Thickness:
-
Contact Plating:
Gold
Contact Material:
Phosphor Bronze
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 800 |
| Sales Unit | Piece |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
THD
319 Products
TAIHUADA was founded in Shenzhen.
It successfully developed ultra-small Pitch FPC:0.3Pitch 0.5Pitch, height: 1.0h, 1.2h, 1.5h, 2.0h and other series of ultra-thin and high-precision products .
