ST ST13009
Manufacturer:
ST
Mfr. Part #:
ST13009
Package:
TO-220
Customer #:
Key Attributes:
TRANS NPN 700V 12A TO-220
Description:
Bipolar (BJT) Transistor NPN 700V 12A 100W Through Hole TO-220
Datasheet:
ST ST13009
Products Specifications
Manufacturer:
Package:
TO-220
Emitter-Base Voltage(Vebo):
12V
Current - Collector Cutoff:
500uA
DC Current Gain:
15@5A,5V
Transition frequency(fT):
-
Vce Saturation(VCE(sat)):
1.25V
type:
NPN
Pd - Power Dissipation:
100W
Current - Collector(Ic):
12A
Collector - Emitter Voltage VCEO:
700V
Operating Temperature:
-65℃~+150℃
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 50 |
| Sales Unit | Piece |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
ST
9271 Products
STMicroelectronics is a global independent semiconductor company and a leader in developing and delivering semiconductor solutions across the spectrum of microelectronics applications. An unrivaled combination of silicon and system expertise, manufacturing strength, Intellectual Property (IP) portfolio, and strategic partners positions, STMicroelectronics is at the forefront of System-on-Chip (SoC) technology and its products play a key role in enabling today's convergence trends.
