SGMICRO SGM8542XS/TR
Manufacturer:
SGMICRO
Asian Brands
Mfr. Part #:
SGM8542XS/TR
Package:
SOIC-8
Customer #:
Key Attributes:
1.1MHz, 46uA, Rail-to-Rail I/O, CMos Operational Amplifiers
Description:
3.5mV 0.5pA 520V/ms 71dB 2.1V~5.5V 1.1MHz 2 Rail-to-Rail Input, Rail-to-Rail Output SOIC-8 Amplifiers RoHS
Datasheet:
SGMICRO SGM8542XS/TR
Products Specifications
Manufacturer:
Package:
SOIC-8
Vos - Input Offset Voltage:
3.5mV
Ib - Input Bias Current:
0.5pA
Slew Rate:
520V/ms
Common Mode Rejection Ratio(CMRR):
71dB
Quiescent Current(Iq):
89uA
Operating Temperature:
-40℃~+125℃
Output Current:
85mA
Voltage - Supply:
2.1V~5.5V
Gain Bandwidth Product:
1.1MHz
Input Offset Voltage Drift(Vos TC):
2.7uV/℃
Maximum Power Supply Range (Vdd-Vss):
5.5V
Number of Channels:
2
Rail To Rail:
Rail-to-Rail Input, Rail-to-Rail Output
Input Offset Current(Ios):
0.5pA
Noise density(eN):
27nV/√Hz@1kHz
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 4000 |
| Sales Unit | Piece |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
SGMICRO
2842 Products
SG Micro Corp
(hereinafter referred to as "SGMICRO") was founded in 2007 by engineering veterans. It is focused on the development, manufacturing, and sales of comprehensive analog and mixed-signal integrated circuit (IC) solutions. Since its inception, the company has targeted various industrial applications as its core customer base and gradually expanded the width of its product line from operational amplifiers and LDOs to complete conditioning links of analog signals and mixed signals, and complete system power management product lines. The company aims to become the world's leading integrated analog integrated circuit provider. While continuing to develop its industrial customer business, it maintains a strong adaptability to the world's most dynamic communications and information-related consumer electronics applications. Its products are widely used in factory automation, photovoltaic inverter systems, new energy, white appliances, communications, automated office equipment, mac
