RENESAS ISL78444AVEZ-T7A
Manufacturer:
RENESAS
Mfr. Part #:
ISL78444AVEZ-T7A
Package:
HTSSOP-14-EP
Customer #:
Key Attributes:
100V Boot, 4A Peak, Half-Bridge Driver with Single PWM Input and Adaptive Dead Time Control
Description:
HTSSOP-14-EP Gate Drivers RoHS
Datasheet:
RENESAS ISL78444AVEZ-T7A
Products Specifications
Manufacturer:
Package:
HTSSOP-14-EP
Input Logic Level - Low:
1V~1.3V
Peak Output Current(Source):
3A
Peak Output Current(Sink):
4.5A
Quiescent Current(Iq):
500uA
Input Voltage (Vin):
8V~18V
Driven Configuration:
Half-Bridge
Operating Temperature:
-40℃~+140℃
Propagation Delay tpLH:
40ns
Propagation Delay tpHL:
55ns
Rise Time:
10ns
Features:
Under Voltage Protection
Fall Time:
10ns
Load Type:
MOSFET
Input Logic Level - High:
1.7V~2.1V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 250 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8542399000 |
| USHTS | 8542390001 |
| TARIC | 8542399000 |
| CAHTS | 8542390000 |
| BRHTS | 85423999 |
| INHTS | 85423900 |
| MXHTS | 8542.39.99 |
