RENESAS NP36P06KDG-E1-AY
Manufacturer:
RENESAS
Mfr. Part #:
NP36P06KDG-E1-AY
Package:
TO-263
Customer #:
Description:
60V 36A 29.5mΩ@10V,18A 1 P-Channel TO-263 Single FETs, MOSFETs RoHS
Datasheet:
RENESAS NP36P06KDG-E1-AY
Products Specifications
Manufacturer:
Package:
TO-263
Drain to Source Voltage:
60V
Current - Continuous Drain(Id):
36A
Operating Temperature -:
-55℃~+175℃
RDS(on):
29.5mΩ@10V,18A
Gate Threshold Voltage (Vgs(th)):
-
Number:
1 P-Channel
Input Capacitance(Ciss):
3.1nF@10V
Pd - Power Dissipation:
1.8W;56W
Gate Charge(Qg):
54nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 800 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
