RENESAS NP36P04SDG-E1-AY
Manufacturer:
RENESAS
Mfr. Part #:
NP36P04SDG-E1-AY
Package:
TO-252(MP-3ZK)
Customer #:
Key Attributes:
P-channel, Current: 36A, Voltage: 40V
Description:
40V 36A 23.5mΩ@4.5V 2.5V@250uA 1 P-Channel 56W TO-252(MP-3ZK) Single FETs, MOSFETs RoHS
Datasheet:
RENESAS NP36P04SDG-E1-AY
Products Specifications
Manufacturer:
Package:
TO-252(MP-3ZK)
Drain to Source Voltage:
40V
Current - Continuous Drain(Id):
36A
RDS(on):
23.5mΩ@4.5V
Operating Temperature -:
-55℃~+175℃
Gate Threshold Voltage (Vgs(th)):
2.5V@250uA
Type:
P-Channel
Reverse Transfer Capacitance (Crss@Vds):
280pF
Number:
1 P-Channel
Output Capacitance(Coss):
450pF
Pd - Power Dissipation:
56W
Input Capacitance(Ciss):
2.8nF@10V
Gate Charge(Qg):
55nC
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 2500 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
