PULSE DPX1608LL66R2455A
Manufacturer:
PULSE
Mfr. Part #:
DPX1608LL66R2455A
Package:
SMD-6P,0.8x1.6mm
Customer #:
Description:
10dB 15dB SMD-6P,0.8x1.6mm RF Multiplexers RoHS
Datasheet:
PULSE DPX1608LL66R2455A
Products Specifications
Category:
Manufacturer:
Package:
SMD-6P,0.8x1.6mm
High band insertion loss (Max):
0.9dB
Low Band Attenuation (Min):
10dB
Low band return loss (Min):
10dB
Operating Temperature:
-40℃~+85℃
Low band insertion loss (Max):
0.95dB
High Band Attenuation (Min):
15dB
High band return loss (Min):
10dB
High band range:
4.9GHz~6GHz
Low band range:
2.4GHz~2.5GHz
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 4000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8548000001 |
| USHTS | 8548000000 |
| TARIC | 8548009099 |
| CAHTS | 8548000000 |
| BRHTS | 85480010 |
| INHTS | 85480000 |
| MXHTS | 8548.10.01 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
PULSE
2490 Products
Pulse Electronics is one of the world's largest electronic component manufacturers and a leader in passive, magnetic-based components. Pulse's products are used in computers, networking and telecommunications, power conversion, defense, aerospace and consumer electronics. With both catalog parts and custom design capability, Pulse is a complete source for electronic OEMs and CEMs worldwide.
