PANJIT PJQ4466AP-AU_R2_000A1
Manufacturer:
PANJIT
Asian Brands
Mfr. Part #:
PJQ4466AP-AU_R2_000A1
Package:
DFN3333-8
Customer #:
Description:
60V 21mΩ@10V,15A 2.5V 1 N-channel DFN3333-8 Single FETs, MOSFETs RoHS
Datasheet:
PANJIT PJQ4466AP-AU_R2_000A1
Products Specifications
Manufacturer:
Package:
DFN3333-8
Drain to Source Voltage:
60V
Current - Continuous Drain(Id):
6A;33A
Operating Temperature -:
-55℃~+175℃@(Tj)
RDS(on):
21mΩ@10V,15A
Gate Threshold Voltage (Vgs(th)):
2.5V
Reverse Transfer Capacitance (Crss@Vds):
85pF@20V
Number:
1 N-channel
Input Capacitance(Ciss):
1.68nF@20V
Pd - Power Dissipation:
2.4W;53W
Gate Charge(Qg):
28nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 5000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
PANJIT
1418 Products
Innovation, Development, Responsibility, Sustainability
PANJIT is a public company founded in May 1986. We are a discrete manufacturer, a member of Electronic Industry Citizenship Coalition (EICC), and have ISO/TS-16949, ISO-9001, OHSAS-18001 certifications.
PANJIT is vertical integrated. We self-design and produce the wafer and manufacture our products. With insight observation and core technologies, PANJIT is able to continuously launch low profile products and accurate power rating devices which conforms to the customer needs.
PANJIT commits to serve customers with the best service, thus we have established sales offices worldwide. We have sites in North America, Germany, Korea and China which allows us to provide better and prompt service.
