PANJIT PJD85N03_L2_00001
Manufacturer:
PANJIT
Asian Brands
Mfr. Part #:
PJD85N03_L2_00001
Package:
TO-252
Customer #:
Description:
30V 3.8mΩ 2.5V 1 N-channel 58W TO-252 Single FETs, MOSFETs RoHS
Datasheet:
PANJIT PJD85N03_L2_00001
Products Specifications
Manufacturer:
Package:
TO-252
Configuration:
-
Drain to Source Voltage:
30V
Current - Continuous Drain(Id):
-
Operating Temperature -:
-55℃~+150℃@(Tj)
RDS(on):
3.8mΩ
Gate Threshold Voltage (Vgs(th)):
2.5V
Reverse Transfer Capacitance (Crss@Vds):
196pF@25V
Number:
1 N-channel
Input Capacitance(Ciss):
2.436nF@25V
Pd - Power Dissipation:
58W
Gate Charge(Qg):
23nC@4.5V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 3000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
PANJIT
1418 Products
Innovation, Development, Responsibility, Sustainability
PANJIT is a public company founded in May 1986. We are a discrete manufacturer, a member of Electronic Industry Citizenship Coalition (EICC), and have ISO/TS-16949, ISO-9001, OHSAS-18001 certifications.
PANJIT is vertical integrated. We self-design and produce the wafer and manufacture our products. With insight observation and core technologies, PANJIT is able to continuously launch low profile products and accurate power rating devices which conforms to the customer needs.
PANJIT commits to serve customers with the best service, thus we have established sales offices worldwide. We have sites in North America, Germany, Korea and China which allows us to provide better and prompt service.
