PANJIT PJL9836A_R2_00001
Manufacturer:
PANJIT
Mfr. Part #:
PJL9836A_R2_00001
Package:
SOP-8
Customer #:
Description:
60V 6A 24mΩ@4.5V,3A 2.5V@250uA 2 N-Channel 1.7W SOP-8 Single FETs, MOSFETs RoHS
Datasheet:
PANJIT PJL9836A_R2_00001
Products Specifications
Manufacturer:
Package:
SOP-8
Drain to Source Voltage:
60V
Current - Continuous Drain(Id):
6A
Operating Temperature -:
-55℃~+150℃
RDS(on):
24mΩ@4.5V,3A
Gate Threshold Voltage (Vgs(th)):
2.5V@250uA
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
85pF
Number:
2 N-Channel
Output Capacitance(Coss):
115pF
Pd - Power Dissipation:
1.7W
Input Capacitance(Ciss):
1.68nF
Gate Charge(Qg):
28nC@10V
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
