PANJIT PJQ5606_R2_00001
Manufacturer:
PANJIT
Mfr. Part #:
PJQ5606_R2_00001
Package:
DFN5060B-8
Customer #:
Description:
30V 25A 45mΩ@4.5V,2A 2.5V@250uA 1 N-Channel + 1 P-Channel 21W DFN5060B-8 Single FETs, MOSFETs RoHS
Datasheet:
PANJIT PJQ5606_R2_00001
Products Specifications
Manufacturer:
Package:
DFN5060B-8
Drain to Source Voltage:
30V
Current - Continuous Drain(Id):
25A
Operating Temperature -:
-55℃~+150℃
RDS(on):
45mΩ@4.5V,2A
Gate Threshold Voltage (Vgs(th)):
2.5V@250uA
Type:
N-Channel + P-Channel
Reverse Transfer Capacitance (Crss@Vds):
76pF
Number:
1 N-Channel + 1 P-Channel
Output Capacitance(Coss):
120pF
Pd - Power Dissipation:
21W
Input Capacitance(Ciss):
846pF
Gate Charge(Qg):
7.8nC@4.5V
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
PANJIT
1418 Products
Innovation, Development, Responsibility, Sustainability
PANJIT is a public company founded in May 1986. We are a discrete manufacturer, a member of Electronic Industry Citizenship Coalition (EICC), and have ISO/TS-16949, ISO-9001, OHSAS-18001 certifications.
PANJIT is vertical integrated. We self-design and produce the wafer and manufacture our products. With insight observation and core technologies, PANJIT is able to continuously launch low profile products and accurate power rating devices which conforms to the customer needs.
PANJIT commits to serve customers with the best service, thus we have established sales offices worldwide. We have sites in North America, Germany, Korea and China which allows us to provide better and prompt service.
