PANJIT BAT54WS_R1_00001
Manufacturer:
PANJIT
Mfr. Part #:
BAT54WS_R1_00001
Package:
SOD-323
Customer #:
Description:
Diode 30V 200mA Surface Mount SOD-323
Datasheet:
PANJIT BAT54WS_R1_00001
Products Specifications
Manufacturer:
Package:
SOD-323
Non-Repetitive Peak Forward Surge Current:
1A
Reverse Leakage Current (Ir):
2uA@25V
Operating Junction Temperature Range:
-55℃~+125℃
Voltage - DC Reverse (Vr) (Max):
30V
Voltage - Forward(Vf@If):
600mV@100mA
Current - Rectified:
200mA
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541100000 |
| USHTS | 8541100040 |
| TARIC | 8541100000 |
| CAHTS | 8541100090 |
| BRHTS | 85411011 |
| INHTS | 85411000 |
| MXHTS | 8541.10.01 |
