onsemi NCP3135MNTXG
Manufacturer:
onsemi
Mfr. Part #:
NCP3135MNTXG
Package:
QFN-16-EP(3x3)
Customer #:
Key Attributes:
5A Synchronous Buck Converter
Description:
1.1MHz Buck Adjustable 5A QFN-16-EP(3x3) Voltage Regulators - DC DC Switching Regulators RoHS
Datasheet:
onsemi NCP3135MNTXG
Products Specifications
Category:
Manufacturer:
Package:
QFN-16-EP(3x3)
Operating Temperature:
-40℃~+125℃
Frequency - Switching:
1.1MHz
Function:
Buck
Number of Outputs:
1
Output Type:
Adjustable
Topology:
Buck
Operating Voltage:
2.9V~5.5V
Switch tube (built-in/external):
Built-in
Output Current:
5A
Output Voltage:
-
Quiescent Current:
2.2mA
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 3000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8542399000 |
| USHTS | 8542390001 |
| TARIC | 8542399000 |
| CAHTS | 8542390000 |
| BRHTS | 85423999 |
| INHTS | 85423900 |
| MXHTS | 8542.39.99 |
