Nichicon UHV1V122MHD
Manufacturer:
Nichicon
Mfr. Part #:
UHV1V122MHD
Package:
Through Hole,D12.5xL25mm
Customer #:
Description:
1200uF 35V ±20% 3.19A@100kHz Through Hole,D12.5xL25mm Aluminum Electrolytic Capacitors RoHS
Datasheet:
Nichicon UHV1V122MHD
Products Specifications
Manufacturer:
Package:
Through Hole,D12.5xL25mm
Operating Temperature:
-40℃~+105℃
Lifetime:
-
Capacitance:
1200uF
Height - Seated (Max):
25mm
Pin Spacing:
5mm
Voltage Rating:
35V
Diameter:
12.5mm
Equivalent Series Resistance(ESR):
-
Tolerance:
±20%
Ripple Current:
3.19A@100kHz
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8532229000 |
| USHTS | 8532230020 |
| TARIC | 8532220000 |
| CAHTS | 8532220000 |
| BRHTS | 85322200 |
| INHTS | 85322200 |
| MXHTS | 8532.22.99 |
