Products Specifications
Manufacturer:
Package:
DO-27(DO-201AD)
Non-Repetitive Peak Forward Surge Current:
150A
Reverse Leakage Current (Ir):
5uA
Reverse Recovery Time (trr):
35ns
Diode Configuration:
1 Independent
Voltage - DC Reverse (Vr) (Max):
400V
Operating Junction Temperature Range:
-55℃~+150℃
Voltage - Forward(Vf@If):
1.25V@3A
Current - Rectified:
3A
Additional Information
| Type | Details |
|---|---|
| Minimum | 10 |
| Multiple | 10 |
| Standard Packaging | 1250 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541100000 |
| USHTS | 8541100040 |
| TARIC | 8541100000 |
| CAHTS | 8541100090 |
| BRHTS | 85411011 |
| INHTS | 85411000 |
| MXHTS | 8541.10.01 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
NH
591 Products
NH, established in October 2012, focuses on the research, development, production, and sales of diode and bridge rectifier chips and packaging. The company mainly produces diode chips, including general rectifier diodes, fast recovery diodes, high-efficiency diodes, Schottky diodes, Zener diodes, transient voltage suppressor diodes, and bridge rectifiers.
