muRata PLT09HN2003R0P1B
Manufacturer:
muRata
Mfr. Part #:
PLT09HN2003R0P1B
Package:
Through Hole
Customer #:
Key Attributes:
CMC 20uH 3A 2LN TH
Description:
20uH 2Line Common Mode Choke Through Hole 3A DCR 30mΩ
Datasheet:
muRata PLT09HN2003R0P1B
Products Specifications
Category:
Manufacturer:
Package:
Through Hole
Inductance @ Frequency:
20uH
Insulation Resistance(IR):
10MΩ
Operating Temperature:
-40℃~+85℃
DC Resistance(DCR):
30mΩ
Voltage Rating - DC:
50V
Number of Lines:
2
Voltage Withstand:
125V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 100 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8548900001 |
| USHTS | - |
| TARIC | - |
| CAHTS | - |
| BRHTS | - |
| INHTS | - |
| MXHTS | - |
