MICROCHIP APTM50H14FT3G

MICROCHIP APTM50H14FT3G

Name: MICROCHIP APTM50H14FT3G
Brand: MICROCHIP

Manufacturer: MICROCHIP

Mfr. Part #: APTM50H14FT3G

Package: -

Customer #:

Description: 500V 26A 168mΩ@10V,13A 5V 4 N-Channel 208W Single FETs, MOSFETs RoHS

Datasheet: MICROCHIP APTM50H14FT3G

Products Specifications

Manufacturer:

MICROCHIP

Package:

Configuration:

Half-Bridge

Drain to Source Voltage:

500V

Current - Continuous Drain(Id):

26A

Operating Temperature -:

-40℃~+150℃@(Tj)

RDS(on):

168mΩ@10V,13A

Gate Threshold Voltage (Vgs(th)):

Number:

4 N-Channel

Pd - Power Dissipation:

208W

Input Capacitance(Ciss):

3.259nF@25V

Gate Charge(Qg):

72nC@10V

Compliance & Export Codes

Type	Details
RoHS
ECCN	EAR99
CNHTS	8541290000
USHTS	8541290095
TARIC	8541290000
CAHTS	8541290000
BRHTS	85412910
INHTS	85412900
MXHTS	8541.29.99
