MICROCHIP MSC180SMA120S

MICROCHIP MSC180SMA120S

Name: MICROCHIP MSC180SMA120S
Brand: MICROCHIP

Manufacturer: MICROCHIP

Mfr. Part #: MSC180SMA120S

Package: TO-268

Customer #:

Description: 1.2kV 21A 225mΩ@20V,8A 3.26V 1 N-channel 125W TO-268 Single FETs, MOSFETs RoHS

Datasheet: MICROCHIP MSC180SMA120S

Products Specifications

Category:

Discrete Semiconductors/FETs, MOSFETs/Single FETs, MOSFETs

Manufacturer:

MICROCHIP

Package:

TO-268

Drain to Source Voltage:

1.2kV

Current - Continuous Drain(Id):

21A

Operating Temperature -:

-55℃~+175℃@(Tj)

RDS(on):

225mΩ@20V,8A

Gate Threshold Voltage (Vgs(th)):

3.26V

Number:

1 N-channel

Pd - Power Dissipation:

125W

Input Capacitance(Ciss):

510pF@1000V

Gate Charge(Qg):

34nC@20V

Additional Information

Type	Details
Minimum	1
Multiple	1
Standard Packaging	1
Sales Unit	Piece

Compliance & Export Codes

Type	Details
RoHS
ECCN	EAR99
CNHTS	8541290000
USHTS	8541290095
TARIC	8541290000
CAHTS	8541290000
BRHTS	85412910
INHTS	85412900
MXHTS	8541.29.99
