MICROCHIP MSCSM170AM058CD3AG
Manufacturer:
MICROCHIP
Mfr. Part #:
MSCSM170AM058CD3AG
Package:
-
Customer #:
Description:
1.7kV 353A 7.5mΩ@20V,180A 3.3V 2 N-Channel 1.642kW Single FETs, MOSFETs RoHS
Datasheet:
MICROCHIP MSCSM170AM058CD3AG
Products Specifications
Manufacturer:
Package:
-
Drain to Source Voltage:
1.7kV
Current - Continuous Drain(Id):
353A
Operating Temperature -:
-40℃~+175℃@(Tj)
RDS(on):
7.5mΩ@20V,180A
Gate Threshold Voltage (Vgs(th)):
3.3V
Number:
2 N-Channel
Pd - Power Dissipation:
1.642kW
Input Capacitance(Ciss):
19.8nF@1000V
Gate Charge(Qg):
1.068uC@20V
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
