MaxLinear XR76205EL-F
Manufacturer:
MaxLinear
Mfr. Part #:
XR76205EL-F
Package:
QFN-30(5x5)
Customer #:
Key Attributes:
40V 3A/5A/8A Synchronous Step Down COT Regulators
Description:
100kHz~800kHz Buck Adjustable 600mV~40V 5A QFN-30(5x5) Voltage Regulators - DC DC Switching Regulators RoHS
Datasheet:
MaxLinear XR76205EL-F
Products Specifications
Category:
Manufacturer:
Package:
QFN-30(5x5)
Operating Temperature:
-40℃~+125℃@(TJ)
Frequency - Switching:
100kHz~800kHz
Function:
Buck
Number of Outputs:
1
Output Type:
Adjustable
Topology:
Buck
Operating Voltage:
5V~40V
Switch tube (built-in/external):
Built-in
Output Voltage:
600mV~40V
Output Current:
5A
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 490 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8542399000 |
| USHTS | 8542390001 |
| TARIC | 8542399000 |
| CAHTS | 8542390000 |
| BRHTS | 85423999 |
| INHTS | 85423900 |
| MXHTS | 8542.39.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
MaxLinear
706 Products
MaxLinear, founded in 2003, is a company focused on the design of RF, analog, digital, and mixed-signal integrated circuits. It primarily produces RF receivers and modems, as well as broadband communication and data connectivity solutions.
