Products Specifications
Manufacturer:
Package:
DO-214AC(SMA)
Non-Repetitive Peak Forward Surge Current:
175A
Reverse Leakage Current (Ir):
500uA@40V
Operating Junction Temperature Range:
-55℃~+150℃
Voltage - DC Reverse (Vr) (Max):
40V
Diode Configuration:
Independent
Voltage - Forward(Vf@If):
550mV@5A
Current - Rectified:
5A
Additional Information
| Type | Details |
|---|---|
| Minimum | 10 |
| Multiple | 10 |
| Standard Packaging | 5000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541100000 |
| USHTS | 8541100040 |
| TARIC | 8541100000 |
| CAHTS | 8541100090 |
| BRHTS | 85411011 |
| INHTS | 85411000 |
| MXHTS | 8541.10.01 |
