Leiditech LM5D50P10
Manufacturer:
Leiditech
Asian Brands
Mfr. Part #:
LM5D50P10
Package:
DFN-8(5x6)
Customer #:
Key Attributes:
MOSFET P-CH 100V 50A DFN-8(5x6)
Description:
P-Channel 100V 50A 140W Surface Mount DFN-8(5x6)
Datasheet:
Leiditech LM5D50P10
Products Specifications
Manufacturer:
Package:
DFN-8(5x6)
Drain to Source Voltage:
100V
Current - Continuous Drain(Id):
50A
RDS(on):
62mΩ@4.5V
Operating Temperature -:
-55℃~+150℃
Gate Threshold Voltage (Vgs(th)):
2.5V@250uA
Type:
P-Channel
Reverse Transfer Capacitance (Crss@Vds):
13pF@50V
Number:
1 P-Channel
Pd - Power Dissipation:
140W
Input Capacitance(Ciss):
2.12nF@50V
Gate Charge(Qg):
40nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 5000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
