JIAENSEMI JNCF120R016ZJ2
Manufacturer:
JIAENSEMI
Asian Brands
Mfr. Part #:
JNCF120R016ZJ2
Package:
TO-247-4
Customer #:
Description:
1.2kV 120A 20mΩ 4V 430W TO-247-4 Single FETs, MOSFETs RoHS
Datasheet:
JIAENSEMI JNCF120R016ZJ2
Products Specifications
Manufacturer:
Package:
TO-247-4
Drain to Source Voltage:
1.2kV
Current - Continuous Drain(Id):
120A
Operating Temperature -:
-55℃~+175℃
RDS(on):
20mΩ
Gate Threshold Voltage (Vgs(th)):
4V
Reverse Transfer Capacitance (Crss@Vds):
11pF
Input Capacitance(Ciss):
6.145nF
Output Capacitance(Coss):
230pF
Pd - Power Dissipation:
430W
Gate Charge(Qg):
200nC
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 30 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | - |
| USHTS | - |
| TARIC | - |
| CAHTS | - |
| BRHTS | - |
| INHTS | - |
| MXHTS | - |
