HUASHUO HSS3132A
Manufacturer:
HUASHUO
Asian Brands
Mfr. Part #:
HSS3132A
Package:
SOT-23
Customer #:
Key Attributes:
MOSFET N-CH 30V 1A SOT-23
Description:
30V 1A 220mΩ@4.5V 700mV 1 N-channel 750mW SOT-23 Single FETs, MOSFETs RoHS
Datasheet:
HUASHUO HSS3132A
Products Specifications
Manufacturer:
Package:
SOT-23
Drain to Source Voltage:
30V
Current - Continuous Drain(Id):
1A
RDS(on):
220mΩ@4.5V
Operating Temperature -:
-55℃~+150℃
Gate Threshold Voltage (Vgs(th)):
700mV
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
4pF
Number:
1 N-channel
Input Capacitance(Ciss):
51pF
Pd - Power Dissipation:
750mW
Output Capacitance(Coss):
8pF
Gate Charge(Qg):
1.5nC@4.5V
Additional Information
| Type | Details |
|---|---|
| Minimum | 50 |
| Multiple | 50 |
| Standard Packaging | 3000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
