HUASHUO HSP18N20A
Manufacturer:
HUASHUO
Asian Brands
Mfr. Part #:
HSP18N20A
Package:
TO-220
Customer #:
Key Attributes:
MOSFET N-CH 200V 18A TO-220
Description:
N-Channel 200V 18A 85W Through Hole TO-220
Datasheet:
HUASHUO HSP18N20A
Products Specifications
Manufacturer:
Package:
TO-220
Drain to Source Voltage:
200V
Current - Continuous Drain(Id):
18A
Operating Temperature -:
-55℃~+150℃
RDS(on):
120mΩ@10V
Gate Threshold Voltage (Vgs(th)):
3.5V@250uA
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
5.3pF
Number:
1 N-channel
Output Capacitance(Coss):
887pF
Input Capacitance(Ciss):
887pF@100V
Pd - Power Dissipation:
85W
Gate Charge(Qg):
14nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 100 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
HUASHUO
618 Products
Huashuo Semiconductor Co., Ltd.
(hereinafter referred to as "HUASHUO") is a semiconductor device company focusing on independent research and development, sales and service. HUASHUO adheres to the principle of "developing new technologies, manufacturing new products, and creating new solutions." It has the design capabilities of a full range of medium/low voltage Power MOSFET discrete devices and special process ICs. The products are widely used in computers, automotive electronics, industrial electronics, consumer electronics, communication power supplies, lithium batteries and other new energy industries.
