Products Specifications
Manufacturer:
Package:
SOP-8
Drain to Source Voltage:
150V
Current - Continuous Drain(Id):
1.6A
RDS(on):
780mΩ@10V
Operating Temperature -:
-55℃~+150℃
Gate Threshold Voltage (Vgs(th)):
4V@250uA
Reverse Transfer Capacitance (Crss@Vds):
13pF
Number:
1 P-Channel
Input Capacitance(Ciss):
706pF
Output Capacitance(Coss):
23pF
Pd - Power Dissipation:
2W
Gate Charge(Qg):
10.8nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 3000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
HL
282 Products
HL is located in Shenzhen, China, and is a national high-tech enterprise focusing on MCUs, motor drivers, and system control. The company primarily produces microcontroller units (MCUs), motor driver chips, and related products for system control.
